Traefik 2.2 + Docker: Global entrypoint configuration

Entrypoint defaults with Traefik 2.2
By containeroo |
Header image

Image Source

Introduction

With Traefik 2.2 it is now easier then ever to globally configure your entrypoints.

We will show you how you can define a global redirect to https and how to set a default certResolver. So you don’t have to set the https redirect in each docker-compose file.

Prerequisites

In order to follow along, you’ll need to read the advanced Traefik guide and the wildcard guide first!

Update Traefik Configuration

Change the entrypoints in the basic Traefik configuration file (/opt/containers/traefik/data/traefik.yml) as follows:

entryPoints:
  http:
    address: :80
    http:
      redirections:
        entryPoint:
          to: https
  https:
    address: :443
    http:
      middlewares:
        - default-headers@file
      tls:
        certResolver: cloudflare
        domains:
          - main: example.com
            sans:
              - "*.example.com"

The file will then look like this:

api:
  dashboard: true
  debug: true

entryPoints:
  http:
    address: ":80"
    http:
      redirections:
        entryPoint:
          to: https
  https:
    address: ":443"
    http:
      middlewares:
        - default-headers@file
      tls:
        certResolver: cloudflare
        domains:
          - main: example.com
            sans:
              - "*.example.com"

providers:
  docker:
    endpoint: "unix:///var/run/docker.sock"
    exposedByDefault: false
  file:
    filename: /config.yml

certificatesResolvers:
  http:
    acme:
      email: email@email.com
      storage: acme.json
      httpChallenge:
        entryPoint: http

We added 2 things:

  1. Global middleware default-headers@file

    By default all containers will now have the defined headers from the /opt/containers/traefik/data/config.yml created in the advanced guide.

  2. Global certResolver cloudflare

    Since we’re using wildcard domains, you’ll need to setup dns challenge first! If you get an error like this:

    level=error msg=”middleware \”default-headers@file\” does not exist” routerName=traefik@docker entryPointName=https”

    Please make sure you have the middleware default-headers created in /opt/containers/traefik/data/config.yml. If not, either create it or remove the middleware from the traefik.yml.

Because we defined the https redirect and the certResolver here, you can remove some labels from all your docker-compose.

The Traefik docker-compose (/opt/containers/traefik/docker-compose.yml) now looks like this:

version: "3"

services:
  traefik:
    image: traefik:v2.2
    container_name: traefik
    restart: unless-stopped
    security_opt:
      - no-new-privileges:true
    networks:
      - proxy
    ports:
      - 80:80
      - 443:443
    environment:
      - CF_API_EMAIL=your-cloudflare@email.com
      - CF_API_KEY=your-cloudflare-api-key
    volumes:
      - /etc/localtime:/etc/localtime:ro
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - ./data/traefik.yml:/traefik.yml:ro
      - ./data/acme.json:/acme.json
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.traefik.entrypoints=https"
      - "traefik.http.routers.traefik.rule=Host(`traefik.example.com`)"
      - "traefik.http.middlewares.traefik-auth.basicauth.users=USER:PASSWORD"
      - "traefik.http.routers.traefik.middlewares=traefik-auth"
      - "traefik.http.routers.traefik.service=api@internal"

networks:
  proxy:
    external: true

The Portainer docker-compose (/opt/containers/portainer/docker-compose.yml) now looks like this:

version: "3"

services:
  portainer:
    image: portainer/portainer:latest
    container_name: portainer
    restart: unless-stopped
    security_opt:
      - no-new-privileges:true
    networks:
      - proxy
    volumes:
      - /etc/localtime:/etc/localtime:ro
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - ./data:/data
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.portainer.entrypoints=https"
      - "traefik.http.routers.portainer.rule=Host(`portainer.example.com`)"
      - "traefik.http.services.portainer.loadbalancer.server.port=9000"
      - "traefik.docker.network=proxy"

networks:
  proxy:
    external: true

As you can see, you only need 5 instead of 11 labels.

Additional Individual Middlewares

If you want to add more individual middlewares, you can still add them to your docker-compose. In this example we’ve added a redirect regex required for Nextcloud (line 4, 5, 6 and 7):

labels:
  - "traefik.enable=true"
  - "traefik.http.routers.nextcloud.rule=Host(`nextcloud.example.com`)"
  - "traefik.http.middlewares.nextcloud-redirectregex.redirectregex.regex=https://(.*)/.well-known/(card|cal)dav"
  - "traefik.http.middlewares.nextcloud-redirectregex.redirectregex.replacement=https://$$1/remote.php/dav/"
  - "traefik.http.middlewares.nextcloud-redirectregex.redirectregex.permanent=true"
  - "traefik.http.routers.nextcloud.middlewares=nextcloud-redirectregex"
  - "traefik.http.routers.nextcloud.service=nextcloud"
  - "traefik.http.services.nextcloud.loadbalancer.server.port=80"
  - "traefik.docker.network=proxy"
